Measurement section
Indicators

• Green lamp Indicates an approved breaking chamber
• Red lamp Indicates a defect breaking chamber, lights up if the current exceeds 0.3 mA
• Yellow lamp Indicate that the test was interrupted

Output

• Standard voltages, switchable
• 10, 14, 25, 40 and 60 kV DC
• Customized voltage Between 10 and 60 kV DC. Determined at the factory Default
• voltage is 50 kV.
• Ripple Max 3%

General

• Mains voltage 115 / 230 V AC (switchable),
• 50 / 60 Hz
• Power consumption 69 VA (max)
• Protection Overload cut-out

Dimensions

• Instrument 250 x 210 x 125 mm
• Transport case 460 x 430 x 210 mm
• Weight 6.9 kg (15.5 lbs)
• 10.7 kg (23.6 lbs) with accessories and transport case
• Operating 0°C to +50°C (32°F to +122°F)
• Storage & transport -40°C to +70°C (-40°F to +158°F)
• Humidity 5% – 95% RH, non-condensing
