Measurement section

• Voltmeter – digital
• Range 0 – 300 V DC, 0 – 300 V AC
• Resolution 1 V
• Inaccuracy ±1% of displayed value, DC
• ±2.5% of displayed value, AC
• Current shunt 5 A / 50 mV ±0.5% (built-in)

Outputs (DC), CATII

• COIL, CLOSING/BREAKING
• Output voltage 24-300 V DC
• Load interval Max 1 s (at currents over 50 mA)
• Ripple 2% peak-to-peak of the preset voltage
• No-load voltage (V) Current (A) Load dependency
• 24 10 < 6 %
• 48 10 < 3 %
• 110 7.9 < 2 %
• 250 3 < 2 %
• 300 1.25 < 2 %

Outputs (AC), CATII
COIL, CLOSING/BREAKING

• Output voltage 24-300 V AC
• Load current Max 5 A
• Load interval Max 30 min

Output DC, CATII
MOTOR

• Output voltage 24-300 V DC (loaded)

General

• Mains voltage 115 / 230 (135 / 250) V AC, 50 / 60 Hz
• Power consumption (max) 3300 W
• 29.3 kg (64.6 lbs) with accessories and transport case
• Operating 0°C to +50°C (32°F to +122°F)
• Storage & transport -40°C to +70°C (-40°F to +158°F)
• Humidity 5% – 95% RH, non-condensing
